The clock has run out on Google Summer of Code 2016.  In this post I’ll summarize the feedback we received on the new UI design and the work I’ve been doing since my last post.

Feedback on the New UI Design

A number of people shared their feedback on the new UI design by posting comments on the previous blog post.  The response was generally positive.  Here’s a brief summary:

• One commenter advocated for keeping the current date/time picker design, while another just wanted to be sure to keep quick and easy text entry.
• A question about how attendees availability would be shown (same as it is currently).
• A request to consider following Google Calendar’s reminders UI.
• A question about preserving the vertical scroll position across different tabs (this should not be a problem).
• A concern about how the design would scale for very large numbers (say hundreds) of attendees, categories, reminders, etc.  (See my reply.)

Thanks to everyone who took the time to share their thoughts.  It is helpful to hear different views and get user input.  If you have not weighed in yet, feel free to do so, as more feedback is always welcome.  See the previous blog post for more details.

Coding the Summer Away

A lot has happened over the last couple months.  The big news is that I finished porting the current UI from the window dialog to a tab.  Here’s a screenshot of this XUL-based implementation of the UI in a tab (click to enlarge):

Getting this working in a really polished way took more time than I anticipated, largely because the code had to be refactored so that the majority of the UI lives inside an iframe.  This entailed using asynchronous message passing for communication between the iframe’s contents and its outer parent context (e.g. toolbars, menus, statusbar, etc.), whether that context is a tab or a dialog window.  While this is not a visible change, it was necessary to prepare the way for the new HTML-based design, where an HTML file will be loaded in the iframe instead of a XUL file.

Along with the iframe refactoring, there are also just a lot of details that go into providing an ideal user experience, all the little things we tend to take for granted when using software.  Here’s a list of some of these things that I worked on over the last months for the XUL implementation:

• when switching tabs, update the toolbar and statusbar to reflect the current tab
• persist open tabs across application restarts (which requires serializing the tab state)
• ask the user about saving changes before closing a tab, before closing the application window, and before quitting the application
• allow customizing toolbars with the new iframe setup
• provide a default window dialog height and width with the new iframe setup
• display icons for tabs and related CSS/style work
• get the relevant ‘Events and Tasks’ menu items to work for a task in a tab
• allow hiding and showing the toolbar from the view > toolbars menu
• if the user has customized their toolbar for the window dialog, migrate those settings to the tab toolbar on upgrade
• fix existing mozmill tests so they work with the new iframe setup
• test for regressions in SeaMonkey

In the next two posts I’ll describe how to try out this new feature in a development version of Thunderbird, discuss the HTML implementation of the new UI design, and share some thoughts on using React for the HTML implementation.

— Paul Morris

As you can see on the Event in a Tab wiki page, I have created a number of mockups, labeled A through N, for the new UI for creating, viewing, and editing calendar events and tasks.  (This has given me a lot of practice using Inkscape!)  The final design will be implemented in the second phase of the project.  So far the revisions have been based on valuable feedback from Paenglab and MakeMyDay (thanks!), and we are now seeking broader feedback from users on the latest and greatest mockup “N” (click to view full size):

Event in a Tab, UI Design, Mockup “N”

Please take a look and send any feedback, comments, suggestions, questions, etc. to the calendar mailing list / newsgroup where we will be discussing the design, or you can leave a comment on this blog post, send a private email to mozilla@kewis.ch, or reach us via IRC (in Mozilla’s #calendar channel).

Here are some notes and details about the behavior of the proposed UI that are not apparent from a static image.

The mockup is intended as a relatively rough “wire frame” to show layout and it only approximates spacing, sizing, and aesthetic details. Unless otherwise noted, functionality is the same as in the current Lightning add-on.

A responsive design approach will be used to implement this UI in HTML. As the window expands horizontally, the elements will expand with it up to a breakpoint where the two-column “tab” layout goes into effect. Then the elements will continue to expand in both of the columns, up to a certain maximum limit at which they would expand no further. (Having this limit will keep things more focused on very wide monitors/windows.)

For vertical scrolling in a tab… Categories, Reminders, Attachments, Attendees, and Description can expand to take up as much vertical space as necessary to show all of their content. In most cases, where there are only a small number of these items, there will be enough room on the page to show them all without any scrolling. In less common cases where there are many items, the content of the tab will grow taller until it no longer fits vertically, and then the whole tab will become scrollable. (The toolbar at the top, with the buttons like “Save and Close,” will not scroll, remaining in place, still easily accessible.) This approach makes it possible to view all of the items at once when there are many of them (instead of having smaller boxes around each of these elements that are each independently scrollable).  This “whole tab scrolling” approach is how it works in Google Calendar.

For vertical scrolling in a dialog window…  When the contents of the tabbed box (Reminders, Attachments, Attendees, and Description) becomes too big to fit vertically, the tabbed box becomes scrollable.  (Suggestions are welcome for the name of the “More” tab in the window dialog.)

The mockup shows the new date/time picker that is being developed by Mozilla.  It remains to be seen whether it will be available in time for use in this project.  Another possibility is the date/time picker developed by Fastmail.

Progress Report on Coding

Besides working on the design for the UI, I have continued to work on porting the current event dialog UI to a tab.  I created a bug for this part of the first phase of the project, posted my first work-in-progress patch there, and am now working on the next iteration based on the feedback.

This work includes refactoring the current event dialog’s XUL file into more than one file to separate the main part of the UI from its menu bar, tool bar, and status bar items.  This more modular arrangement will make it possible to make the menu bar, tool bar, and status bar items appear in the correct places in the main Thunderbird window when displaying the UI in a tab.  This will solve the problem of the doubled status bar and menu bar in my first patch.

The next patch will also have a hidden preference (accessible via “about:config” but eventually to be added to Lightning’s preferences UI) that determines whether event and task dialogs are opened in a window or a tab by default.

So overall, things are progressing well, which is a good thing since there is only about a week or so left before the GSoC midterm milestone, and the goal is to have phase one of the project completed by that point.  After I have finished this initial “phase one” patch, and any follow-up work that needs to be done for it, we will reach a decision about whether to use XUL, Web Components, React.js, or “plain vanilla” HTML for the implementation of the new UI design, and then start working on implementing it.

— Paul Morris

Time for a progress report after my first week or so working on the Event in a Tab GSoC project. Things are going well so far. In short, I have the current event and task dialogs opening in a tab rather than a window and I can create and edit tasks and events in a tab. While not everything is working yet most things already are.

The trickiest part has been working with XUL, since I am not as familiar with it as I am with Javascript. With some help from Fallen on IRC I figured out how to register a new XUL document that contains an iframe and how to load another XUL file into this iframe. For an event or task that is editable one XUL file is loaded (calendar-event-dialog.xul), but if it is read-only then a different XUL file is loaded (calendar-summary-dialog.xul).

Initially I used the tabmail interface’s “shared tab” option — where a single XUL file is loaded and then its appearance and content is modified to create the appearance of completely different tabs. (This is how Thunderbird’s “3-pane” and “single message” tabs work, and also Lightning’s “Calendar” and “Tasks” tab.) However, this did not work when you opened multiple events/tasks in separate tabs. So I figured out the tabmail interface’s other option which loads each tab separately as you would expect and everything is now working fine.

The next step was to figure out how to access the data for an event (or task) from the tab. I actually figured out two ways to do this. The first was via the tabmail interface in the way that it is set up to work (i.e. “tabmail.currentTabInfo”). That meant that the current event dialog code (that referenced the data as a property of the “window” object) had to be changed to access it from this new location.  But that is not so good since we will be supporting both window and tab options and it would be nice if the same code could “just work” for both cases as much as possible.

So I figured out a second way to provide access to the data by just putting it in the right place relative to the iframe, so that the current code could reach it without having to be modified (i.e. still as a property of the “window” object, but with the “window” being relative to the iframe). This is a better approach since the same code will work for both cases (events/tasks in a dialog window or in a tab).

One small thing I implemented via the tabmail interface is that the title of the tab indicates whether you are creating a new item or modifying an existing one and whether the item is an event or a task. However, I will probably end up re-working this because the current dialog window code updates the title of the window as you change the title of the event/task, and that code can probably also be used to generate the initial title of the tab. This is something I will be looking into as I start to really work with the event dialog code.

On the UI design side of things, I created three new mockups based on some more feedback from Richard Marti and MakeMyDay. Part of the challenge is that there are a number of elements that vary in size depending on how many items they contain (e.g. reminders, categories, attachments, attendees). Mockups K and L were my attempt at a slightly different approach for handling this, although we will be following the design of mockup J going forward. You can take a look at these mockups and read notes about them on the wiki page.

The next steps will be to push toward a more finalized design and seek broader feedback on it.  On the coding side I will be identifying where things are not working yet and getting them to work. For example, the code for closing a window does not work from a tab and the status bar items are appearing just above the status bar (at the bottom of the window) because of the iframe.

So far I think things are going well. It is really encouraging that I am already able to create and modify events and tasks from a tab and that most of the basic functionality appears to be working fine.

— Paul Morris

Today is the first day of the “coding period” for Google Summer of Code 2016 and I’m excited to be working on the “Event in a Tab” project for Mozilla Calendar. The past month of the “community bonding period” has flown by as I made various preparations for the summer ahead. This post covers what I’ve been up to and my experience so far.

After the exciting news of my acceptance for GSoC I knew it was time to retire my venerable 2008 Apple laptop which had gotten somewhat slow and “long in the tooth.” Soon, with a newly refurbished 2014 laptop via Ebay in hand, I made the switch to GNU/Linux, dual-booting the latest Ubuntu 16.04. Having contributed to LilyPond before it felt familiar to fire up a terminal, follow the instructions for setting up my development environment, and build Thunderbird/Lightning. (I was even able to make a few improvements to the documentation – removed some obsolete info, fixed a typo, etc.) One difference from what I’m used to is using mercurial instead of git, although the two seem fairly similar. When I was preparing my application for GSoC my build succeeded but I only got a blank white window when opening Thunderbird. This time, thanks to some guidance from my mentor Philipp about selecting the revision to build, everything worked without any problems.

One of the highlights of the bonding period was meeting my mentors Philipp Kewisch (primary mentor) and MakeMyDay (secondary mentor). We had a video chat meeting to discuss the project and get me up to speed. They have been really supportive and helpful and I feel confident about the months ahead knowing that they “have my back.” That same day I also listened in on the Thunderbird meeting with Simon Phipps answering questions about his report on potential future legal homes for Thunderbird, which was an interesting discussion.

At this point I am feeling pretty well integrated into the Mozilla infrastructure after setting up a number of accounts – for Bugzilla, MDN, the Mozilla wiki, an LDAP account for making blog posts and later for commit access, etc. I got my feet wet with IRC (nick: pmorris), introduced myself on the Calendar dev team’s mailing list, and created a tracker bug and a wiki page for the project.

Following the Mozilla way of working in the open, the wiki page provides a public place to document the high-level details related to design, implementation, and the overall project plan. If you want to learn more about this “Event in a Tab” project, check out the wiki page.  It contains the mockup design that I made when applying for GSoC and my notes on the thinking behind it. I shared these with Richard Marti who is the resident expert on UI/UX for Thunderbird/Calendar and he gave me some good feedback and suggestions. I made a number of additional mockups for another round of feedback as we iterate towards the final design. One thing I have learned is that this kind of UI/UX design work is harder than it looks!

Additionally, I have been getting oriented with the code base and figuring out the first steps for the coding period, reading through XUL documentation and learning about Web Components and React, which are two options for an HTML implementation. It turns out there is a student team working on a new version of Thunderbird’s address book and they are also interested in using React, so there will be a larger conversation with the Thunderbird and Calendar dev teams about this. (Apparently React is already being used by the Developer Tools team and the Firefox Hello team.)

I think that about covers it for now. I’m excited for the coding period to get underway and grateful for the opportunity to work on this project. I’ll be posting updates to this blog under the “gsoc” tag, so you can follow my progress here.

— Paul Morris
